Honeywell M9184E4006/U Modutrol IV Motor Non-Spring Return

Product Description

The Honeywell Modutrol IV Motor, M9184E4006/U, is designed to provide reliable performance for HVAC control systems. This non-spring return motor is engineered for applications requiring accurate positioning of dampers and valves. With a torque rating of one hundred fifty in-pounds and operating on twenty-four volts, it ensures efficient operation in various environments.

• Integral junction box offers NEMA 3 weather protection when mounted upright.
• Field-adjustable stroke ranging from ninety to one hundred sixty degrees.
• Dual shafts that are slotted and tapped on both ends for flexible mounting options.

Product Highlights

The modulating motor features quick-connect terminals for easy installation and maintenance. Optional auxiliary switches can be added for enhanced functionality. This motor operates within a wide temperature range, accommodating various HVAC environments.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: M9184E4006/U

Technical Specifications

• Power Consumption: 15 VA
• Torque Rating: 150 in-lb
• Operating Conditions: -40 F to 150 F
• Electrical Connections: Quick-Connect Terminals
• Auxiliary Switch: 1
