Honeywell M9164D1009/U Modutrol IV Motor Non-Spring Return

Product Description

The Honeywell M9164D1009/U is a Modutrol IV motor designed for precise control in HVAC applications. It operates at 24 volts and has a torque rating of thirty-five in-lbs. The motor is ideal for proportional control and features a 135 ohm control signal. Key functionalities include an integral junction box for NEMA three weather protection, ensuring durability in various environments.

• Foot mount for installation versatility.
• Adjustable stroke between ninety and one hundred sixty degrees.
• Quick-connect terminals for easy electrical integration.

Product Highlights

This motor is suitable for a range of applications including commercial heating, ventilation, and air conditioning systems. Designed to maintain fixed torque throughout its voltage range, the M9164D1009/U provides reliable performance under various conditions.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: M9164D1009/U

Technical Specifications

• Power Consumption: 10 VA
• Torque Rating: 35 in-lb
• Timing: 30-60 seconds
• Operating Conditions: -40 F to 150 F
• Temperature Range: -40 to 150 F
• Electrical Connections: Quick-connect terminals
• Style: Dampers and Damper Actuators
