Honeywell M6415A1016/U Economizer Damper Actuator Spring Return

Product Description

The Honeywell M6415A1016/U is an economizer damper actuator designed for effective control in HVAC systems. This actuator features a torque rating of twenty-five in-lbs and operates on twenty-four volts with an eight VA power consumption. The spring return mechanism ensures that the motor shaft returns to its normal position in the event of a power failure.

• Synchronous motor provides efficient operation.
• Constructed from high impact, glass-fiber reinforced plastic for durability.
• Compatible with direct digital control systems.

Product Highlights

This actuator is suitable for use in economizer applications across commercial buildings, providing precise control of ventilation and combustion air dampers.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: M6415A1016/U

Technical Specifications

• Torque Rating: 25 lb-in
• Power Consumption: 8 VA driving, 3 VA holding
• Operating Temperature Range: -25 F to 125 F
• Electrical Connections: Quick-connect terminals
• Dimensions: 4.5 inches high x 5 inches wide x 5.1875 inches deep
• Weight: 3 lbs
• Operating Humidity Range: 5 to 95% relative humidity, non-condensing
• Mounting: Foot-mounted
