Honeywell M6285F1001-F/U Modutrol IV Motor Spring Return

Product Description

The Honeywell M6285F1001-F/U is a Modutrol IV motor designed for HVAC applications. This motor features a torque rating of sixty in-lbs and operates at twenty-four volts with a twenty-one VA power requirement. It provides floating control and includes linear ten-kilohm feedback.

• Spring return motor for reliable operation
• Compatible with normally open or normally closed valves
• Adjustable stroke from ninety to one hundred sixty degrees

Product Highlights

This motor ensures dependable performance in HVAC systems, with built-in features for easy integration and adjustment.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: M6285F1001-F/U

Technical Specifications

• Torque Rating: 60 in-lb
• Power Supply: 24V AC
• VA Rating: 21 VA
• Control Type: Floating
• Feedback Type: Linear 10K
• Weather Protection: NEMA 3 when mounted upright
• Internal Potentiometer: Yes
• Field Adjustable Stroke: 90 to 160 degrees
