Honeywell M6285C1001-S Modutrol IV Motor 24V 60 lb-in with Dual Internal Auxiliary Switches

Product Description

Discover the robust and efficient Honeywell M6285C1001-S, a 24V non-spring return floating control motor from the acclaimed Modutrol IV series. This motor is perfect for controlling dampers and valves in various commercial and industrial settings.

• Equipped with an internal feedback potentiometer for precise shaft position indication.
• Offers NEMA 3 weather protection when mounted upright.
• Includes integral auxiliary switches and dual-ended shafts for enhanced functionality.

Product Highlights

The Honeywell M6285C1001-S motor features adjustable stroke from 90 to 160 degrees and operates efficiently with a 15 VA power consumption during driving. Suitable for both normally open and normally closed configurations, it includes a foot-mounted design and square-shaped shaft for easy installation and stability.

Technical Specifications

• Application Type: Electric, Non-Spring Return
• Control Signal: Floating
• Motor Shaft: Dual-ended, 0.375 inches square
• Stroke: Adjustable, 90 to 160 degrees
• Power Consumption: 15 VA
• Mounting: Foot-mounted
• Temperature Range: -40 to 150°F
• Auxiliary Switch Ratings: AFL - 120 Vac: 7.2A, AFL - 240 Vac: 3.6A
