Honeywell M4185B1009/U Modutrol IV Motor, Spring Return

Product Description

The Honeywell M4185B1009/U is a Modutrol IV electric motor designed for HVAC applications. It operates at one hundred twenty volts and has a torque rating of sixty inch-pounds. This motor features a spring return mechanism to ensure that it returns to the normal position when power is lost.

• Fixed torque is maintained throughout the entire voltage range
• Designed for either normally open or closed valve applications
• Integral junction box provides protection from weather if mounted upright

Product Highlights

This motor is suitable for controlling dampers and valves in HVAC systems. It has dual shafts for flexible installation options and allows adjustments for stroke length.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: M4185B1009/U

Technical Specifications

• Power Consumption: 20 VA
• Auxiliary Switches: 1
• Operating Conditions: -40 F to 150 F (-40 C to 60 C)
• Electrical Connection: Quick Connect Terminals
• Dimensions: 5.5 inches W x 8.75 inches D x 6.4375 inches H
• Torque Rating: 60 in-lb
• Voltage Rating: 120 VAC
• Series: M4185
