Honeywell ipc3k28se-adf28kmc-dl-i0 8MP Binocular Camera

Product Description

The HONEYWELL ipc3k28se-adf28kmc-dl-i0 is an 8-megapixel binocular eyeball-style IP security camera built around a 1/2.5-inch CMOS sensor and dual-lens splicing technology that delivers a 180-degree horizontal field of view in a single unit. Running at up to 20 frames per second at full 4096 x 1860 resolution, it captures wide-area coverage without the distortion of a single fisheye lens. The 130 dB true wide dynamic range handles high-contrast lighting conditions, and ColorHunter technology maintains full-color imaging around the clock using both 850 nm infrared and warm-light illuminators rated to 30 meters. A licensed security integrator or surveillance technician is the typical installer for this class of camera.

This camera is suited for commercial and high-end residential perimeter surveillance where wide-angle, full-color nighttime coverage is required. Typical deployment scenarios include building facades, parking lots, retail entrances, and other locations where a single camera must cover a broad horizontal zone. Smart intrusion prevention uses target classification to distinguish humans, motor vehicles, and non-motor vehicles from environmental triggers such as leaves, birds, and changing light conditions, reducing false alarms. Intelligent people-flow counting and crowd-density monitoring extend its utility to traffic-analysis and occupancy applications. Built-in dual microphones, a speaker, and alarm I/O support two-way audio and integrated alarm response workflows.

Key Features

• Dual-lens splicing technology achieves a true 180-degree horizontal field of view without fisheye distortion
• ColorHunter full-color imaging supported by both IR and warm-light illuminators, each effective to 30 meters
• 130 dB true WDR for clear imaging in high-contrast and backlit scenes
• Smart intrusion prevention with AI-based target classification reduces nuisance alarms
• Integrated people-flow counting and crowd-density monitoring for occupancy analytics
• Built-in dual microphones and speaker with 1 alarm input and 1 alarm output for on-camera audio and alert functions
• MicroSD card slot supports local storage up to 512 GB

Compatibility

Designed as an IP network camera compatible with standard ONVIF-compliant video management systems and network video recorders that support H.265 or H.264 streams. Confirm NVR channel licensing and bandwidth capacity before installation.

Installation Notes

Installation should be performed by a licensed security systems technician familiar with IP camera commissioning and structured cabling standards. Power down or disconnect the network switch port before making cable terminations. Ensure the mounting surface can support the camera weight and that conduit or cable routing meets applicable local codes. Do not apply power before verifying that the lens assembly and housing seals are fully secured.

Technical Specifications

• Resolution: 8 MP (4096 x 1860)
• Sensor: 1/2.5-inch CMOS
• Frame Rate: 20 fps at 8 MP
• Field of View (Horizontal): 180 degrees
• Field of View (Vertical): 65 degrees
• Field of View (Diagonal): 180 degrees
• Focal Length: 2.8 mm
• Iris: Fixed, F1.0
• WDR: 130 dB
• Min. Illumination: 0.002 Lux (F1.0, AGC ON) color; 0 Lux with supplemental light
• Supplemental Light Type: Dual light (850 nm IR and warm light)
• Illumination Range: 30 meters (98.4 feet) IR; 30 meters (98.4 feet) warm light
• IR On/Off Control: Auto/Manual
• Day/Night: IR-cut filter with auto switch (ICR)
• Shutter: Auto/Manual, 1 to 1/100000 s
• S/N Ratio: Greater than 52 dB
• Adjustment Angle: Pan 0 to 360 degrees, Tilt 0 to 75 degrees, Rotate 0 to 360 degrees
• DORI Detect Distance: 63.1 meters (207.0 feet)
• DORI Observe Distance: 25.2 meters (82.7 feet)
• DORI Recognize Distance: 12.6 meters (41.3 feet)
• DORI Identify Distance: 6.3 meters (20.7 feet)
• Alarm I/O: 1 input / 1 output
• Audio I/O: 1 input / 1 output
• Built-in Audio: Dual microphone and speaker
• Local Storage: MicroSD, up to 512 GB

Standard Information

• Brand: HONEYWELL
• Manufacturer Part Number: ipc3k28se-adf28kmc-dl-i0
