Honeywell ipc3638se-adf28k-wl-i0 8MP Turret Network Camera

Product Description

The HONEYWELL ipc3638se-adf28k-wl-i0 is an 8-megapixel fixed warm light turret-style IP security camera built around a 1/1.8-inch CMOS sensor. It delivers full-color, 24-hour surveillance using ColorHunter technology combined with an F1.0 super aperture, maintaining color imaging down to 0.0005 Lux without infrared. The camera supports 120 dB true wide dynamic range (WDR) for clear imaging in high-contrast lighting conditions. It encodes in Ultra 265, H.265, H.264, and MJPEG. This unit is installed by security integrators and low-voltage technicians in commercial and residential surveillance applications.

This camera is suited for indoor and outdoor fixed-mount surveillance where 24-hour full-color imaging is required without auxiliary IR illumination. The IK10 vandal-resistant housing and IP67 weatherproof rating make it appropriate for exterior mounting in exposed locations. It supports 9:16 corridor mode for hallways and stairwells. Smart intrusion prevention with target classification filters out false alarms triggered by environmental factors such as leaves, birds, and changing light, focusing detections on humans, motor vehicles, and non-motor vehicles. Intelligent people flow counting and crowd density monitoring expand its use in higher-density commercial environments.

Key Features

• 8 MP (3840 x 2160) resolution at up to 30 fps with 1/1.8-inch CMOS sensor
• ColorHunter technology with F1.0 super aperture enables full-color imaging to 0.0005 Lux
• 120 dB true WDR for clear imaging in strong backlight or high-contrast scenes
• Smart intrusion prevention with cross-line, intrusion, enter area, and leave area detection based on target classification
• IK10 vandal-resistant and IP67-rated housing for exterior installation
• MicroSD card support up to 512 GB for onboard edge storage
• Alarm I/O (1 in / 1 out) and audio I/O (1 in / 1 out) for integrated system connections

Compatibility

Designed as an OEM-style fixed turret network camera for integration into IP-based video management systems supporting Ultra 265, H.265, H.264, or MJPEG video streams.

Installation Notes

Installation is typically performed by licensed low-voltage or security systems technicians. Power down or de-energize the network switch port before making connections. Follow local codes governing low-voltage wiring and camera mounting hardware. Do not exceed the MicroSD card capacity rating of 512 GB for onboard storage.

Technical Specifications

• Max Resolution: 8 MP (3840 x 2160)
• Sensor: 1/1.8-inch CMOS
• Frame Rate: Up to 30 fps (8 MP, intelligent off) / 25 fps
• Min. Illumination: Color 0.0005 Lux (F1.0, AGC ON)
• Aperture: F1.0
• WDR: 120 dB
• S/N Ratio: Greater than 56 dB
• Shutter: Auto/Manual, 1 to 1/100000 s
• Adjustment Angle: Pan 0 degrees to 360 degrees, Tilt 0 degrees to 72 degrees, Rotate 0 degrees to 360 degrees
• Video Compression: Ultra 265, H.265, H.264, MJPEG
• Onboard Storage: MicroSD up to 512 GB
• Alarm I/O: 1 in / 1 out
• Audio I/O: 1 in / 1 out
• Ingress Protection: IP67
• Impact Rating: IK10

Standard Information

• Brand: HONEYWELL
• Manufacturer Part Number: ipc3638se-adf28k-wl-i0
