Honeywell ipc3634se-adf28k-wl-i0 4MP Turret Network Camera

Product Description

The HONEYWELL ipc3634se-adf28k-wl-i0 is a 4-megapixel fixed turret IP security camera built for 24-hour full-color surveillance in demanding environments. It uses a 1/1.8-inch CMOS sensor with an F1.0 super aperture and ColorHunter technology to deliver full-color images in near-zero-light conditions down to 0.0005 Lux. A built-in warm light illuminator reaches 30 meters (98.4 feet). The camera supports Ultra 265, H.265, H.264, and MJPEG compression with triple simultaneous streams up to 4 MP at 30 fps. Rated IP67 and IK10, it is designed for licensed security integrators and commercial surveillance installers working in both indoor and outdoor environments.

This camera is suited for commercial and light-industrial security installations where continuous color imaging is required around the clock. Smart intrusion prevention functions — including cross-line, intrusion, enter-area, and leave-area detection — use target classification to differentiate humans, motor vehicles, and non-motor vehicles, reducing false alarms from environmental triggers such as foliage movement and lighting changes. People flow counting and crowd density monitoring make it applicable in retail, transit, and access-control scenarios. The 9:16 corridor mode supports narrow-aisle and hallway deployments. Power is supplied via PoE (IEEE 802.3af) or DC 12 volts, keeping cabling simple in new and retrofit installations.

Key Features

• ColorHunter technology with F1.0 aperture delivers full-color imaging at minimum illumination of 0.0005 Lux
• 120 dB true Wide Dynamic Range (WDR) for clear imaging in high-contrast lighting scenes
• Smart intrusion prevention with human, motor vehicle, and non-motor vehicle classification to reduce false alarms
• Built-in warm light illuminator with effective range of 30 meters (98.4 feet)
• IK10 vandal resistance and IP67 weatherproof rating for harsh indoor and outdoor locations
• MicroSD edge storage up to 512 GB plus ANR and NAS (NFS) network storage support
• ONVIF Profile S, G, T, and M compatible with two-way audio and built-in microphone

Compatibility

Compatible with ONVIF Profile S, Profile G, Profile T, and Profile M systems. Supported client software includes EZStation and the associated mobile app. Web browser live view is supported on IE 10 and later, Chrome 45 and later, Firefox 52 and later, and Edge 79 and later with plug-in; plug-in-free live view is available on Chrome 57 and later, Firefox 58 and later, and Edge 16 and later.

Installation Notes

Installation should be performed by a licensed security or low-voltage technician in accordance with local electrical codes and NEC low-voltage wiring requirements. Disconnect power at the source before wiring alarm inputs, audio connections, or the coaxial power plug. When using PoE, confirm the switch or injector meets IEEE 802.3af requirements before connecting. Mount on a stable surface using appropriate anchors for the substrate; the turret head provides pan 0 to 360 degrees, tilt 0 to 75 degrees, and rotation 0 to 360 degrees for precise aiming after mounting.

Technical Specifications

• Max Resolution: 4 MP (2688 x 1520)
• Sensor: 1/1.8-inch CMOS
• Min. Illumination: 0.0005 Lux (F1.0, AGC ON)
• Aperture: F1.0
• Focal Length Options: 2.8 mm, 4.0 mm
• Horizontal Field of View: 110.4 degrees (2.8 mm), 88.2 degrees (4.0 mm)
• WDR: 120 dB
• Signal-to-Noise Ratio: greater than 56 dB
• Warm Light Illumination Distance: 30 m (98.4 feet)
• Video Compression: Ultra 265, H.265, H.264, MJPEG
• Frame Rate: Up to 30 fps at 4 MP
• Video Bit Rate: 128 Kbps to 16 Mbps
• Video Streams: Triple streams
• Audio Compression: G.711U, G.711A
• Audio I/O: 1 input, 1 output
• Alarm I/O: 1 input, 1 output
• Edge Storage: MicroSD, up to 512 GB
• Network Interface: 1 x RJ45 10 M/100 M Base-TX Ethernet
• Power Input: DC 12 V plus or minus 25%, PoE IEEE 802.3af
• Max Power Consumption: 9.0 W
• Dimensions: 5.1 inches diameter x 4.3 inches height
• Weight: 1.52 pounds
• Material: Metal
• Ingress Protection: IP67
• Impact Resistance: IK10
• Surge Protection: 4 KV
• Operating Temperature: -22 degrees F to 140 degrees F (-30 degrees C to 60 degrees C)
• Operating Humidity: 95% RH or less, non-condensing
• Certifications: CE-EMC, FCC Part 15 Class B, CE LVD, CB, UL 62368-1, CE-RoHS, WEEE, Reach, ONVIF Profile S/G/T/M

Standard Information

• Brand: HONEYWELL
• Manufacturer Part Number: ipc3634se-adf28k-wl-i0
