Honeywell ipc3628sr-adf28km-wp 8MP Turret Network Camera

Product Description

The HONEYWELL ipc3628sr-adf28km-wp is an 8-megapixel turret-style IP security camera built for installations that demand full-color imaging around the clock. It uses a 1/1.8-inch CMOS sensor paired with an F1.0 large-aperture lens and ColorHunter with Wise-ISP technology to produce color video in low-light and no-light conditions without switching to black-and-white mode. The camera supports multiple resolutions up to 3840 x 2160 at 20 fps and encodes in Ultra 265, H.265, H.264, or MJPEG. A built-in microphone, onboard MicroSD slot supporting up to 512 GB, and PoE power input make this a self-contained unit that security installers can deploy with a single Cat5e or Cat6 run.

This camera is suited for commercial and residential surveillance installations where consistent color detail is required in challenging lighting conditions. The 120 dB true wide dynamic range handles scenes with strong backlight or mixed lighting. The warm white light illuminator reaches up to 30 meters, providing visible-spectrum fill light rather than infrared, which supports full-color nighttime footage. The 9:16 corridor mode makes it well-suited for hallways, stairwells, and narrow exterior pathways. It is typically installed by low-voltage security technicians and integrators working on IP-based video surveillance systems.

Key Features

• 8 MP 1/1.8-inch CMOS sensor with F1.0 large-aperture lens for low-light color performance
• ColorHunter and Wise-ISP technology delivers 24-hour full-color imaging
• 120 dB true WDR for clear images in high-contrast or backlit scenes
• Warm white light illumination up to 30 meters (98.4 feet)
• Multi-resolution support: up to 3840 x 2160 at 20 fps or 1080p at 30/25 fps
• MicroSD onboard storage up to 512 GB and PoE power input
• IP67 weatherproof rating and 9:16 corridor mode

Compatibility

Designed for use in IP-based network video surveillance systems supporting PoE-powered turret cameras with ONVIF-style integration. No specific compatible NVR models or system families were identified in the provided product data.

Installation Notes

Installation should be performed by a licensed low-voltage or security systems technician familiar with IP camera deployment and structured cabling. Power down or disconnect the PoE switch port before making or breaking the network connection at the camera. Mount the camera to a solid junction box or surface mount adapter rated for the camera weight and the intended environment. Verify that the MicroSD card is properly seated before closing the housing and confirm IP67 sealing integrity after final mounting to maintain the weatherproof rating.

Technical Specifications

• Resolution: 8 MP (3840 x 2160)
• Sensor: 1/1.8-inch CMOS
• Aperture: F1.0
• Frame Rates: 3840 x 2160 at 20 fps; 3072 x 1728 at 30/25 fps; 2560 x 1440 at 30/25 fps; 1920 x 1080 at 30/25 fps
• Video Compression: Ultra 265, H.265, H.264, MJPEG
• Wide Dynamic Range: 120 dB true WDR
• Illumination: Warm white light, up to 30 meters (98.4 feet)
• Audio: Built-in microphone
• Local Storage: MicroSD, up to 512 GB
• Power Input: PoE
• Ingress Protection: IP67
• Corridor Mode: 9:16 supported

Standard Information

• Brand: HONEYWELL
• Manufacturer Part Number: ipc3628sr-adf28km-wp
