Honeywell ipc3614sr-adf28km-h 4MP Ir Eyeball Camera

Product Description

The HONEYWELL ipc3614sr-adf28km-h is a 4-megapixel fixed IR eyeball network camera built for professional security installations. It uses a 1/3.0-inch CMOS sensor and delivers resolutions up to 2688 x 1520 at 30 frames per second. The unit supports Ultra 265, H.265, H.264, and MJPEG compression codecs, giving installers flexibility in bandwidth and storage management. Easystar low-illumination technology and 120 dB true Wide Dynamic Range (WDR) allow the camera to produce clear images in both low-light and high-contrast scenes. A built-in microphone adds audio capture without additional hardware. Licensed security technicians and low-voltage integrators are the primary installers of this device.

This camera is suited for commercial and residential IP surveillance systems where a discreet, fixed-lens dome-style form factor is required. The eyeball housing allows field-of-view adjustment after mounting. Smart IR with up to 30 meters (98.4 feet) of range makes it practical for corridors, entryways, storage areas, and perimeter coverage. The 9:16 corridor mode is useful for narrow hallways or stairwells. Power over Ethernet (PoE) support simplifies installation by combining power and data on a single Cat cable run. MicroSD card support up to 512 GB enables local edge recording as a backup to NVR-based storage.

Key Features

• 4 MP CMOS sensor at up to 2688 x 1520 resolution, 30 fps
• 120 dB true WDR for clear imaging in high-contrast lighting
• Easystar low-illumination technology for quality images in near-dark conditions
• Smart IR up to 30 meters (98.4 feet)
• PoE power supply support eliminates need for separate power run
• MicroSD slot supports up to 512 GB for local edge recording
• 9:16 corridor mode for narrow-space coverage
• Built-in microphone for integrated audio capture

Compatibility

Designed for use with standard PoE-capable network video recorders and IP surveillance infrastructure. Compatible with systems supporting Ultra 265, H.265, H.264, or MJPEG video streams.

Installation Notes

Installation should be performed by a licensed low-voltage or security systems technician in accordance with local codes and NEC requirements for low-voltage wiring. Power down the PoE switch port before making or breaking the network connection. Confirm the MicroSD card is seated before closing the housing if edge recording is required. Adjust the eyeball position before fully tightening the housing to set the desired field of view.

Technical Specifications

• Resolution: 4 MP (2688 x 1520)
• Frame Rate: Up to 30 fps at 4 MP
• Sensor: 1/3.0-inch CMOS
• WDR: 120 dB true WDR
• IR Distance: Up to 30 meters (98.4 feet)
• Video Compression: Ultra 265, H.265, H.264, MJPEG
• Power Supply: PoE
• Local Storage: MicroSD, up to 512 GB
• Ingress Protection: IP67
• Audio: Built-in microphone
• Corridor Mode: 9:16 supported

Standard Information

• Brand: HONEYWELL
• Manufacturer Part Number: ipc3614sr-adf28km-h
