Honeywell ipc324sr-adf28km-h 4MP Outdoor Ir Dome Ip Camera

Product Description

The HONEYWELL ipc324sr-adf28km-h is a 4MP outdoor fixed dome IP security camera designed for continuous surveillance in demanding conditions. Featuring a 2.8mm fixed lens, it delivers up to 4MP resolution at 30 frames per second, capturing fine detail across a wide field of view. Built-in infrared illumination enables reliable image capture in low-light and no-light environments. Wide Dynamic Range technology balances exposure in scenes with mixed lighting, reducing washout and shadow detail loss. The camera accepts both 12VDC and Power over Ethernet power inputs, giving installers flexibility in how they route power to the unit. This is a professional-grade device intended for installation by qualified security and low-voltage technicians.

The ipc324sr-adf28km-h is suited for outdoor perimeter and entryway surveillance in residential and light commercial applications. The fixed dome form factor fits flush-mount ceiling and overhang installations where a low-profile housing is needed. PoE support simplifies cable runs by combining data and power over a single Cat5e or Cat6 cable, which is common in structured-cabling environments. The 2.8mm lens provides a wider angle of view appropriate for monitoring open areas, parking lots, and building entries where broad scene coverage is the priority.

Key Features

• 4MP image sensor with up to 30 frames per second capture rate
• 2.8mm fixed lens for wide-angle outdoor scene coverage
• Built-in IR night vision for low-light and zero-light surveillance
• Wide Dynamic Range for balanced exposure in high-contrast lighting
• Dual power input: 12VDC or Power over Ethernet for flexible installation
• Fixed dome housing rated for outdoor deployment

Compatibility

Designed as an OEM-style replacement or addition to outdoor IP camera systems supporting standard ONVIF-compatible network video recorders and PoE switches. Verify NVR channel resolution support and PoE budget before installation.

Installation Notes

Installation should be performed by a licensed low-voltage or security technician familiar with IP camera systems and local electrical codes. Before mounting, verify that the PoE switch or injector meets the power budget required by this camera, or confirm a stable 12VDC supply is available. Secure all cable entry points with weatherproof sealant to prevent moisture intrusion into the conduit and housing. Do not power the unit until all network and power connections are fully terminated and inspected.

Technical Specifications

• Resolution: 4MP
• Frame Rate: 30 frames per second
• Lens: 2.8mm fixed
• Power Input: 12VDC or PoE
• Housing Style: Fixed dome
• Installation Environment: Outdoor
• Night Vision: Infrared
• Dynamic Range: Wide Dynamic Range (WDR)

Standard Information

• Brand: HONEYWELL
• Manufacturer Part Number: ipc324sr-adf28km-h
