Honeywell ipc318sr3-adf28km-g 8MP Ir Dome Camera

Product Description

The HONEYWELL ipc318sr3-adf28km-g is an 8-megapixel IR dome network camera built for professional surveillance installations. It uses a 1/3.0-inch CMOS sensor with a maximum resolution of 3840 x 2160 at 20 fps and supports multiple lower resolutions up to 30 fps for flexible bandwidth management. The camera incorporates LightHunter technology for high-quality imaging in low-light conditions, with a minimum illumination of 0.002 Lux in color mode and 0 Lux with IR active. A 120 dB true wide dynamic range (WDR) engine handles high-contrast lighting scenes. Smart IR extends to 30 meters. Licensed security integrators and surveillance technicians are the primary installers.

This dome camera is suited for indoor and outdoor deployments requiring vandal-resistant, weatherproof coverage. Its IK10 impact rating and IP67 environmental protection rating make it appropriate for demanding commercial and industrial environments. The 9:16 corridor mode supports narrow-field applications such as hallways and stairwells. A built-in microphone adds audio capture without a separate device. MicroSD support up to 256 GB provides local edge storage as a backup or standalone recording option.

Key Features

• 8 MP CMOS sensor with multi-stream output: 8 MP at 20 fps, 5 MP and 4 MP at 30/25 fps, 1080p at 30/25 fps
• LightHunter low-light technology with minimum illumination of 0.002 Lux (color) and 0 Lux with IR
• 120 dB true WDR for clear imaging in high-contrast or backlit scenes
• Smart IR with up to 30 meters range; IR-cut filter with auto switch (ICR) for day/night operation
• IK10 vandal resistance and IP67 weatherproof rating
• Supports Ultra 265, H.265, H.264, and MJPEG compression codecs
• PoE power supply support; onboard MicroSD slot up to 256 GB

Compatibility

Designed as an OEM-style replacement and direct-install dome network camera for professional IP surveillance systems supporting PoE-powered IPC endpoints.

Installation Notes

Installation should be performed by a licensed security or low-voltage technician familiar with IP camera commissioning. Power down or disconnect the PoE switch port before making cable terminations. Verify the mounting surface can support the camera housing and allows the full pan range of 0 to 90 degrees, tilt range of 0 to 68 degrees, and rotation range of 0 to 360 degrees before securing the mount. Consult applicable local codes for surveillance equipment placement, particularly in audio-recording jurisdictions where the built-in microphone is active.

Technical Specifications

• Max Resolution: 8 MP (3840 x 2160)
• Sensor: 1/3.0-inch CMOS
• Frame Rates: 8 MP at 20 fps; 5 MP, 4 MP, 1080p at 30/25 fps
• Minimum Illumination: 0.002 Lux color (F1.6, AGC ON); 0 Lux with IR
• Day/Night: IR-cut filter with auto switch (ICR)
• Shutter: Auto/Manual, 1 to 1/100000s
• WDR: 120 dB true WDR
• Signal-to-Noise Ratio: Greater than 52 dB
• IR Distance: Up to 30 meters (98.4 feet)
• Adjustment Angle: Pan 0 to 90 degrees, Tilt 0 to 68 degrees, Rotate 0 to 360 degrees
• Compression: Ultra 265, H.265, H.264, MJPEG
• Local Storage: MicroSD up to 256 GB
• Power Supply: PoE
• Ingress Protection: IP67
• Impact Rating: IK10

Standard Information

• Brand: HONEYWELL
• Manufacturer Part Number: ipc318sr3-adf28km-g
