Honeywell Home V8043F5093 3/4 Inch Sweat Connection Zone Valve + 24V + Single Valve + 272742A Replacement

Product Description

Optimize your heating system efficiency with the Honeywell Home V8043F5093 Zone Valve, strategically engineered for low-voltage operations. This valve is renowned for its reliability in controlling the flow of hot water within your heating systems.

• Effortless installation with compact design allowing placement without disassembly.
• Manual override feature ensures continued operation even during power interruptions.
• Advanced motor technology fortified for silent functionality and enhanced lifespan.

Product Highlights

This zone valve offers a robust construction and is equipped with a screw terminal block connection for easy setup. It is designed to work effectively under a maximum static pressure of 300 psi and an operational voltage of 24V.

Product Information

Standard Information

• Size: 3/4 inch
• Connection Type: Sweat
• Action: Normally closed, spring return to close
• Electrical Connections: Screw terminal block

Technical Specifications

• Maximum Operation Pressure: 300 psi
• Valve Type: Two-way, straight-through
• Fluid Temperature Range: Up to 200 F
• Power Consumption: 7.2 VA
• Dimensions: 4-3/8 inches high x 3-1/2 inches wide x 2-3/8 inches deep
• Voltage: 24V
• Frequency: 60 Hz
