Honeywell GDP1005A 10 Inch 5-speed Benchtop Drill Press

Product Description

The HONEYWELL GDP1005A is a 10-inch, 5-speed benchtop drill press built for workshop use in light industrial, trade shop, and job-site fabrication environments. It runs on a 4.1-amp induction motor engineered for quiet, smooth operation during extended drilling sessions. The 5-speed gearbox lets the operator match spindle speed to material type, and the 5/8-inch chuck accepts larger-diameter bits suited for metal, wood, and composite stock. A built-in LED work light illuminates the work surface directly, improving accuracy on close-tolerance holes. The cast iron base keeps the unit stable under load without requiring anchoring on a solid bench.

This drill press is suited for trade shop applications where consistent, repeatable hole placement is required. Typical users include HVAC fabricators drilling sheet metal brackets, plumbers working with fixture flanges, and electricians drilling enclosure knockouts on the bench. The 7.25-inch by 7.25-inch work table rotates a full 360 degrees and tilts up to 45 degrees, accommodating angled drilling applications. Rack-and-pinion table height adjustment allows fast repositioning between workpieces without tools. The 3-spoke spindle travel handle includes a built-in adjustable depth stop for repeatable blind-hole depths.

Key Features

• 4.1-amp induction motor for quiet, smooth continuous operation
• 5-speed gearbox for matching RPM to material and bit type
• 5/8-inch chuck capacity handles larger-diameter drill bits
• Work table rotates 360 degrees and tilts up to 45 degrees
• Rack-and-pinion table height adjustment for fast, tool-free repositioning
• Built-in LED work light powered by 2 AA batteries
• On/off switch with removable safety key to prevent unauthorized use

Compatibility

Designed as a freestanding benchtop drill press for general workshop and trade fabrication use. No specific system integration is required beyond a standard 120-volt outlet.

Installation Notes

A licensed electrician or knowledgeable tradesperson should verify the bench power circuit meets the motor draw requirements before first use. Place the unit on a flat, stable workbench and confirm all fasteners are tight before powering on. Install the chuck key and Allen wrenches in an accessible location and remove the chuck key from the chuck before starting the motor. Insert the safety key and test the on/off switch function before drilling operations begin.

Technical Specifications

• Swing Capacity: 10 inches
• Motor: 4.1 amps
• Speed Settings: 5-speed gearbox
• Chuck Capacity: 5/8 inches
• Table Size: 7.25 inches x 7.25 inches
• Table Rotation: 360 degrees
• Table Tilt: Up to 45 degrees
• Work Light: LED, 2 AA batteries included
• Base Material: Cast iron
• Weight: 52 pounds
• Includes: Chuck key, Allen wrenches, 2 AA batteries

Standard Information

• Brand: HONEYWELL
• Manufacturer Part Number: GDP1005A
