Honeywell E50-4801600J03KIT Class 500 Meter 277/480V 1600A

Product Description

The Honeywell E50-4801600J03KIT is a Class 500 meter suitable for 277/480V systems with a capacity of 1600A. It comes in a JIC steel enclosure and supports BACnet MS/TP and EZ-7 Ethernet protocols. The meter includes three split-core current sensors, each providing a 2V output for precise current measurement in three-phase systems.

• Designed for 277/480V systems with a maximum capacity of 1600A.
• Supports BACnet MS/TP communication and EZ-7 Ethernet protocols.
• Includes three split-core current sensors with 2V output for accurate readings.

Product Highlights

The Honeywell E50-4801600J03KIT is an essential tool for electrical monitoring and control, making it suitable for various industrial applications.

Product Information

Standard Information

• Brand: Honeywell
• MPN: E50-4801600J03KIT

Technical Specifications

• Voltage (L-N/L-L): 277/480
• Amperage: 1600A
• Configuration Phases: Three Phase
• Enclosure: JIC Steel
• Class: 500
• BACnet MS/TP: Yes
• Current Sensor Output: 2V Output
• Current Sensors Included: 3 Split-Core Sensors
