Honeywell E10017 800 Amp 0-2V Split Core Sensor 3 Piece Set

Product Description

The Honeywell E10017 is a split core sensor set with an amp rating of 800 and a measurement range of 0 to 2 volts. This product integrates seamlessly into metering systems for accurate readings in various applications. The kit includes an enclosure, display, and sensors designed for both indoor and outdoor use.

• Features a dual protocol output supporting simultaneous RS-485 and Ethernet communication.
• Includes a direct-read LCD display for easy viewing of cumulative kilowatt hours.
• Sensors can be mounted remotely up to five hundred feet from the meter.

Product Highlights

The Honeywell E10017 provides reliable performance with a high level of accuracy, making it suitable for industrial settings and energy management systems.

Product Information

Standard Information

• Manufacturer: Honeywell
• MPN: E10017

Technical Specifications

• Supply Voltage: Up to 600 VAC RMS, 50/60Hz
• Communication Protocols: Modbus RTU, TCP/IP, BACnet IP, MS/TP, LonWorks
• Input Configuration: 3-wire (Delta) or 4-wire (WYE)
• CT Input: 0-2 VDC current sensors included
• Overload Rating: Voltage Overload +25% continuously; +100% for 20 cycles; Current Sensor Overload 100% for 1 minute
• Accuracy: Certified to ANSI C12.20
• Operating Temperature: -4 to 158°F for NEMA 4 Housing; -4 to 122°F for NEMA 1 Housing
• Dimensions: Meter: 7.5 inches H x 7 inches W x 3.75 inches D
