Honeywell E10010 100 Amp 0-2V Split Core Sensor 3 Piece Set

Product Description

The Honeywell E10010 is a 100 Amp split core sensor set designed for accurate current measurement and monitoring. This system includes an enclosure, display, and split core current sensors. The device is compatible with various communication protocols including Modbus RTU, BACnet, and LonWorks.

• Features pulse and dual protocol outputs for data collection.
• Includes current sensors that can be mounted remotely.
• Data transmission supports simultaneous RS-485 and Ethernet connections.

Product Highlights

It supports up to 38 data points and measures power accurately within +/− 0.5%. This makes it ideal for monitoring electric consumption in various settings.

Product Information

Standard Information

• Brand: Honeywell
• MPN: E10010

Technical Specifications

• Supply Voltage: Up to 600 VAC RMS available, 50/60Hz
• Voltage Configuration: 3-wire (Delta) or 4-wire (WYE)
• CT Input: 0-2 VDC current sensors included
• Available CT's: 5 Amp - Up to 3200 Amp RMS AC available
• Overload Rating: Voltage Overload +25% continuously; +100% for 20 cycles
• Accuracy: Certified to ANSI C12.20
• Operating Humidity: 0 to 95% RH (non-condensing)
• Enclosure Rating: NEMA 4 (Models with R), NEMA 12 (Models without R)
