Honeywell DTE6-2RN Limit Switch Top Plunger DPDT-2NO/2NC

Product Description

The Honeywell DTE6-2RN Limit Switch is designed for industrial applications where precision and reliability are key. This switch features a top plunger actuator and a DPDT-2NO/2NC contact configuration.

• Top plunger actuator
• DPDT-2NO/2NC contact configuration
• Ideal for industrial applications

Product Highlights

This switch offers reliable performance and is suitable for use in packaging equipment, machinery, and overhead cranes. The Honeywell DTE6-2RN is built to meet industry standards and ensures safety and durability in demanding environments.

Product Information

Standard Information

• Brand: Honeywell
• MPN: DTE6-2RN

Technical Specifications

• Catalog Number: DTE6-2RN
• Manufacturer: Honeywell
• Sub Brand: Microswitch
• UPC: 78454923690
• Item Type: Limit Switches
• Series: E6
• Actuator: Top Plunger
• Material: Die Cast Zinc
• Enclosure: NEMA 1/3/4/IP66
• Application: For packaging equipment, special machinery, textile machinery, conveyors, construction machinery and equipment, printing trades machinery and overhead cranes and hoists
• Contact Configuration: 2NO-2NC/DPDT
• Amperage Rating: 0.15 to 10 A
• Contact Rating: 0.15 to 10 A at 250 VAC/125 VDC
• Voltage Rating: 250 VAC, 125 VDC
• Frequency Rating: 50/60 Hz
• Connection Type: 1/2-14 NPT
• Mounting Type: Side
• Number of Poles: 2
• Operating Cycles: 1000000 Cycles
• Operating Temperature: -32 to 71 deg C
• Standards/Approvals: CE Marked, CSA Certified, UL Listed
