Honeywell DS06-105-SUS-LF Dialset Low Lead Pressure Regulating Valve - Single Union NPT

Product Description

The Honeywell DS06-105-SUS-LF Dialset Low Lead Pressure Regulating Valve with Single Union NPT offers reliable performance. Designed to help reduce the need for a pressure gauge, it features a built-in adjustment dial. The valve also includes a gauge port accessible from both sides if needed.

• Easy installation
• Noncorroding unitized cartridge
• Built-in strainer

Product Highlights

This valve works across a variety of applications, ensuring flexibility and reliability. It's suitable for household, commercial, industrial, and turf-and-irrigation uses.

Product Information

Standard Information

• Brand: Honeywell
• MPN: DS06-105-SUS-LF

Technical Specifications

• Nominal Size: 2 inches
• Pressure Range: 25 to 90 PSI
• Temperature Rating: 140°F
• Body Material: Bronze
• Pressure Rating: 250 PSI
• End Connection: Female Threaded x Female Threaded
• Diaphragm Material: Fabric Reinforced
• Gauge Tap Size: 1/4 inch threaded
• Factory Setting: 60 PSI
• Union Fitting Type: Single Union Soldered
• Model: DS06
