Honeywell DS06-105-DUS-LF Dialset Low Lead Pressure Regulating Valve Double Union Sweat

Product Description

Honeywell DS06-105-DUS-LF is a Dialset Low Lead Pressure Regulating Valve with double union sweat connections. This valve features a built-in adjustment dial that eliminates the need for a pressure gauge when setting the static pressure. An easily accessible gauge port on either side is available if a gauge is needed. It is suitable for installation by a single individual and is reliable enough to reduce callbacks. This valve's flexibility allows it to work in various applications, which can help reduce inventory needs.

• No need for a pressure gauge
• Non-corroding unitized cartridge
• Outlet adjustment range of 25 PSI to 90 PSI

Product Highlights

This product allows for easy pressure setting without gauges, features a non-corroding cartridge, and has an accessible gauge port. It is suitable for household, commercial, industrial, and turf-and-irrigation applications.

Product Information

Standard Information

• Brand: Honeywell
• MPN: DS06-105-DUS-LF
• Category: HVAC Equipment
• Suitable Applications: Household, commercial, industrial, and turf-and-irrigation

Technical Specifications

• Size: 2 inches nominal
• Pressure Rating: 250 PSI
• Temperature Rating: 140 degrees F
• End Connection: Female threaded x Female threaded
• Material: Bronze body
• Downstream Pressure Range: 25 to 90 PSI
• Gauge Tap Size: 1/4 inch threaded
• Factory Setting: 60 PSI
• Union Fitting Type: Double union soldered
