Honeywell DS06-103-SUS-LF Valve 1-1/4 Inch Low Lead Pressure Regulating Single Union NPT

Product Description

The Honeywell DS06-103-SUS-LF Valve 1-1/4 Inch Low Lead Pressure Regulating Single Union NPT is designed for efficient installation and reliable performance. This valve features a built-in adjustment dial that eliminates the need for a pressure gauge when setting the static pressure. It is suitable for a variety of applications including household, commercial, industrial, and irrigation systems.

• Built-in adjustment dial
• Noncorroding unitized cartridge
• Outlet adjustment range of 25 PSI to 90 PSI

Product Highlights

The DS06 DialSet valve simplifies pressure regulation with its built-in adjustment dial. It is designed for single-person installation and reduces inventory needs by being versatile across multiple applications.

Product Information

Standard Information

• Brand: Honeywell
• MPN: DS06-103-SUS-LF

Technical Specifications

• Size: 1-1/4 inches
• Pressure Rating: 250 PSI
• Temperature Rating: 140 degrees Fahrenheit
• Material: Bronze body
• Diaphragm Material: Fabric reinforced
• Connection Type: Female threaded x female threaded
• Downstream Pressure Range: 25 to 90 PSI
• Gauge Tap Size: 1/4 inch threaded
• Standard Factory Setting: 60 PSI
• Certifications: CSA B356, ASSE 1003, IAPMO, UPC, NSF 61
