Honeywell DS06-102-LF Dial Set Pressure Regulating Valve

Product Description

The Honeywell DS06-102-LF Dial Set Pressure Regulating Valve maintains a constant outlet pressure over a wide range of inlet pressures. It is suitable for potable water and irrigation applications.

• Built-In Dial-Set eliminates the need for a pressure gauge when adjusting static pressure.
• Noncorroding Unitized Cartridge contains all working parts and is easily replaceable.
• Outlet adjustment range of 25 PSI to 90 PSI, suitable for various applications.

Product Highlights

This valve is ideal for household, commercial, industrial, and irrigation uses. It can be installed in multiple configurations due to its internal and external threading. Additionally, it includes a built-in strainer for easy maintenance and multiple approvals for compliance.

Product Information

Standard Information

• Brand: Honeywell
• MPN: DS06-102-LF
• Product Type: VALVE
• Model: DS06

Technical Specifications

• Operating Temperature Range: 140 F
• Connection Type: Female NPT Threaded Inlet & Outlet
• Outlet Pressure Adjustment Range: 25-90 PSI
• Max. Inlet Pressure: 250 PSI
• Gauge Tap: 1/4 inch NPT
• Reducing Ratio: 10:1
• Union Fittings: Single-Union Threaded
• Approvals: ASSE 1003, IAPMO, CSA, Low Lead Compliant
