HONEYWELL CTS-10-250-VDC-001 CURRENT SENSOR 0-10VDC 250 AMPS

Product Description

The HONEYWELL CTS-10-250-VDC-001 is a solid core current sensor designed to monitor electrical currents from zero to two hundred fifty amps. This sensor outputs a voltage signal ranging from zero to ten volts DC, which is ideal for use in commercial building management systems.

• Fast response time for accurate readings
• Integral DIN rail for easy installation
• Compatible with cables up to three hundred fifty MCM

Product Highlights

This model ensures reliable monitoring of electrical currents with easy wiring processes.

Product Information

Standard Information

• Application: Ideal for load monitoring in new installations
• Manufacturer: HONEYWELL

Technical Specifications

• Output: 0-10 Vdc
• Current Ratings: 0-100 Amps; 0-200 Amps; 0-250 Amps
• Dimensions: 2 17/64 inches high x 3 3/8 inches wide x 63/64 inches deep
• Frequency: 50 Hz to 60 Hz
• Operating Humidity Range: 0 to 95% RH, non-condensing
• Operating Temperature Range: 5 F to 104 F
• Enclosure Type: UL94-5V/Burgundy
• Response Time: Less than 100 mS
• Isolation Voltage: 2200 Vac
• Weight: 0.22 lb
• DIN Rail Size: 1-3/8 inches
