Honeywell CT230-GA Dual Voltage Line Volt Slave Unit

Product Description

The HONEYWELL CT230-GA dual voltage line volt slave unit is designed for large floor heating applications exceeding 15A. This system separates a floor heating area into zones, with a linked unit responsible for heating each zone. All linked units are controlled by a master thermostat.

• Non-Programmable
• Built-in GFCI/EGFPD with test light
• ON/STANBY switch enables unit's heating area to be shut down independently of other heating areas

Product Highlights

Ideal for zoned floor heating systems, simplifying electrical load distribution and enhancing safety and control across expansive heating zones.

Product Information

Standard Information

• Brand: HONEYWELL
• Manufacturer Part Number: CT230-GA

Technical Specifications

• Application: Electric Heat (Line Voltage)
• Programmability: Non-Programmable
• Mount: Vertical
• Power Method: Hardwired
• Operating Temp Range: 32° to 122°F
• Switch Position: F (Floor Only)
• Switch Action: DPST
• Voltage: 120/240V
• Dual Voltage: Yes
• Manufacturer: Honeywell and Aube
• Manufacturer Part Number: CT230-GA
• Electrical Connection: Double pole, 4 wires, line 1 & line 2
• Connection Method: Hardwired
• Maximum Current: 15 A
• Maximum Load (Resistive Only): 1800 W - 120 V, 3600 W - 240 V, 15 A
• Ground Fault Protection (GFCI): Class A, 5 mA
• SKU: CT230-GA
• UPC (GTIN-12): 881308020514
• Length: 3″
• Weight: 1 lbs
• Width: 2″
