Honeywell CR-DC-5A/U Command Relay 5A SPDT Relay 23-31 VDC

Product Description

The Honeywell CR-DC-5A/U is a 5 Amp SPDT relay designed for reliable performance in various electrical control applications. It operates at a coil voltage of twenty-three to thirty-one point two volts DC. This relay is suitable for situations where current sensing is required, making it ideal for use with Honeywell analog current sensors or switches.

• Mounts on standard thirty-five millimeter DIN rail
• SPDT Form 1C relay contacts
• Includes LED status indication for easy monitoring

Product Highlights

The relay allows for streamlined installations and can be stacked for space efficiency.

Product Information

Standard Information

• Brand: Honeywell
• Manufacturer Part Number: CR-DC-5A/U

Technical Specifications

• Supply Voltage: 23 to 31.2 VDC
• Operating Temperature Range: 5 to 104 °F (-15 to 40 °C)
• Weight: 0.125 lb
• Dimensions: 1.632 inches high x 3.29 inches wide x 1.32 inches deep
• Current Ratings: 5A (NO)/2A (NC) at 250 VAC, 5A (NO)/3A (NC) at 120 VAC
• Operating Humidity Range: 0 to 95% RH, non-condensing
• DIN Rail Size: 1-3/8 inches
