Honeywell CR-230AC-8A/U CR Series Command Relays 8 Amp SPDT Relay 165-264 VAC

Product Description

The Honeywell CR-230AC-8A/U is an 8 Amp SPDT relay designed for various electrical applications. It has a coil voltage range of 165 to 264 VAC, making it suitable for controlling motors, pumps, and fans. The relay’s compact design allows it to be mounted on a standard 35mm Din-Rail for easy installation.

• SPDT Form 1C relay contacts
• Suitable for use with Honeywell analog current sensors
• Stackable design for reduced installation space

Product Highlights

This relay is essential for monitoring electrical equipment and can significantly streamline your control needs.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: CR-230AC-8A/U

Technical Specifications

• Dimensions: 1.632 inches high x 3.29 inches wide x 1.32 inches deep
• Weight: 0.125 lb
• Operating Humidity Range: 0 to 95% RH, non-condensing
• Operating Temperature Range: 5 to 104°F
• Output Switch Rating: 8A at 250 VAC and 30 VDC
• Enclosure Rating: UL94-5VB
• DIN Rail Size: 35 mm
