Honeywell AM101-USTG-1LF 3/4 inches 70-145F Union Temp Gauge

Product Description

The Honeywell AM101-USTG-1LF is a 3/4" union temperature gauge designed for accurately controlling water temperature in domestic hot water systems. It allows for higher water heater storage temperatures, increasing usable hot water while delivering water at a safe, pre-set temperature. The internal thermostatic element automatically adjusts the mix of hot and cold water.

• Accurately controls water temperature for domestic hot water systems
• Allows for a higher storage temperature in the water heater
• Increases the amount of usable hot water

Product Highlights

This mixing valve protects against temperature fluctuations and provides reliable performance for various applications.

Product Information

Standard Information

• Brand: HONEYWELL
• Manufacturer Part Number: AM101-USTG-1LF/U
• Country of Origin: United States

Technical Specifications

• MPN: AM101-USTG-1LF
• Body Material: Brass
• Connection Size 1: 3/4 in
• Connection Size 2: 3/4 in
• Connection Size 3: 3/4 in
• Connection Sizes (Custom): 3/4~3/4~3/4 in
• Connection Type 1: Sweat Union
• Connection Type 2: Sweat Union
• Connection Type 3: Sweat Union
• Connection Types (Custom): Sweat Union~Sweat Union~Sweat Union
• Depth: 4.9 in
• Flow Coefficient: 3.9 Cv
• For Use With: Water Heater
• Function Type: Mixing Valve
• Height: 7.3 in
• Maximum Fluid Temperature: 212 F
• Maximum Working Pressure: 150 PSI
• Media / Fluid Type: Potable Water~Non Potable Water
• Minimum Fluid Temperature: 39 F
• NSF Certified: Yes
• Number of Ports: 3
• Number of Positions: 3
• Package Quantity: 1
• Packaged Depth: 3.6 in
• Packaged Height: 3.7 in
• Packaged Width: 6.1 in
• Pressure Range: 150 PSI
• Product Family: AM100 Series
• Product Type: Mixing Valve
• Temperature Range: 70-145 F
• Width: 4.9 in
• Warranty: 1 Year
