Product Description
The Honeywell 914CE2-6A is a micro switch limit switch designed for various industrial applications. This compact precision limit switch features a top roller plunger and is ideal for use in processing equipment, textile machinery, and robotics.
- Rated for 240 VAC and 5 A
- Includes a six-foot cable for flexible installation
- Meets NEMA and IP standards for durability
Product Highlights
This limit switch is robust and reliable under harsh conditions. It is made of die-cast zinc and supports various actuator options. Its design allows for easy mounting and cable connections.
Product Information
Standard Information
-
Catalog Number: 914CE2-6A
-
Manufacturer: Honeywell
Technical Specifications
-
Actuator: Roller Top Plunger
-
Amperage Rating: 5 A
-
Application: Textile machinery, robotics, packaging equipment
-
Cable Type: Standard cable connection
-
Contact Configuration: 1NO-1NC, SPDT
-
Enclosure Rating: NEMA 1/2/3/3R/4/6/6P/13/IP66/IP67/IP68
-
Frequency Rating: 200/20 Hz
-
Material: Die Cast Zinc
-
Mounting Type: Threaded
-
Operating Cycles: 10,000,000 cycles
-
Operating Temperature: 0 to 105 degrees Celsius
-
Power Rating: 1/10 hp
-
Size: 1.73 in H x 1.57 in W x 0.63 in D
-
Standards: CE Marked, CSA Certified, UL Listed
-
Voltage Rating: 240 VAC
