Honeywell 914CE1-3 Miniature Enclosed Limit Switch 240 VAC 1 Each

Product Description

The Honeywell 914CE1-3 is a miniature enclosed limit switch designed for precise automation control. It operates at 240 VAC and can handle up to 5 A, making it suitable for various applications in industrial settings.

• Compact design with top plunger actuator
• Durable die-cast zinc construction
• Rated for NEMA and IP environmental protection

Product Highlights

This product is ideal for processing equipment, textile machinery, and robotics.

Product Information

Standard Information

• Catalog Number: 914CE1-3
• Manufacturer: Honeywell

Technical Specifications

• Operating Voltage: 240 VAC
• Current Rating: 5 A
• Frequency Rating: 200/20 Hz
• Power Rating: 1/10 hp
• Contact Configuration: 1NO-1NC, SPDT
• Operating Temperature Range: 0 to 105 deg C
• Operating Cycles: 10,000,000
• Dimensions: 1.73 in H x 1.57 in W x 0.63 in D
• Enclosure Type: NEMA 1/2/3/3R/4/6/6P/13/IP66/IP67/IP68
• Material: Die Cast Zinc
• Mounting Type: Threaded
