Honeywell 50027910-001/U Differential Pressure Switch

Product Description

The Honeywell 50027910-001/U is a differential pressure switch designed for HVAC applications. It functions effectively when duct or remote mounted. This switch is ideal for critical HVAC controls.

• Includes necessary installation accessories.
• Pressure setpoint contacts change at 0.04 inches water column.
• Suitable for 24 VAC operation with a current rating of 5 amps resistive.

Product Highlights

A reliable switch for monitoring pressure in environmental systems.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: 50027910-001/U

Technical Specifications

• Mounting Type: Duct or Remote
• Switch Type: SPST
• Maximum Current: 5 Amps at 24 VAC
• Pressure Setpoint Change: 0.04 inches w.c.
• Included Accessories: 2 Rubber Grommets, 2 Tube Fitting Elbows, 10 feet of 1/4 inch O.D. Tubing, 2 #8 x 3/4 inch Sheet Metal Screws, and 2 Terminal Adapters
• Application: For use with installed IAQ equipment including humidification systems
