The Honeywell 45131004 is a 14 AWG, 2 conductor solid, unshielded, FPLP/CL2P/C(UL)/FT6 type cable. Designed for high-performance fire alarm installations in plenum spaces. Its solid copper conductors and low-smoke PVC jacket meet demanding safety codes for commercial buildings.
Offered in multi-conductor constructions
Polypropylene insulation on the conductors of non-plenum constructions
Sunlight-resistant jacket
Product Highlights
This Honeywell Genesis cable is suitable for wiring fire protective signaling circuits and for use with all power-limited circuits except those in plenums.
Product Information
Standard Information
Brand: HONEYWELL
Manufacturer Part Number: 45131004
Technical Specifications
Brand
Honeywell
Manufacturer
GENESIS
Model / MPN
45131004
Product Type
ELECTRONIC_CABLE
Application
For wiring of fire protective signaling circuits
Conductor Size
14 AWG;18 AWG
Conductor Type
Bare Solid Copper
Insulation Material
PVC
Jacket Color
Red/White;Red
Jacket Material
PVC
Length
1000 ft
Number of Conductors
2;4
Resistance
2.5 Ohm;6.5 Ohm
Series
Genesis
Standards/Approvals
UL 13/1424|NEC 725/760|C(UL) FT6|NFPA 262|RoHS Compliant
Temperature Rating
-20 to 75 deg C
Type
Plenum Power Limited Unshielded
Voltage Rating
300 VAC
Conductors
14 AWG solid bare copper conductors
Insulation
Flame-retardant low-smoke plenum-rated PVC insulation and jacket (FPLP)
Feature
Countdown length markings for efficient cable management
