HONEYWELL 110184 Motorized Butterfly Valve

Product Description

The HONEYWELL 110184 is a motorized butterfly valve ideal for heating and cooling systems. This wafer-type valve fits pipe sizes from DN50 to DN500 and can handle pressures up to PN16. It features an electric actuator operating at 220Vac and has built-in stall protection that activates at one hundred twenty-five degrees Celsius. A manual override functionality is included for easy operational control. The valve's design is rated IP67 for waterproof capabilities.

• Suitable for heating and cooling applications.
• Manual override allows for flexible operation.
• Electric actuator includes stall protection for safety.

Product Highlights

This valve is designed for diverse heating and cooling scenarios, ensuring reliable performance with advanced features.

Product Information

Standard Information

• Type: Wafer Type
• Input Voltage: 220Vac

Technical Specifications

• Sizes: DN50 to DN500
• Nominal Pressure: PN16
• Tightness: Bubble tight
• Medium Temperature: -10 °C to +110 °C
• Body Material: IS: 210, FG 220 CI
• Stem Material: ASTM A276, GR SS 410
• Disc Material: Epoxy coated ductile iron
• Disc Liner Material: EPDM
• Medium Type: Chilled and Hot water
• Pipe Connection: ISO7005-2
• Travel Angle: Ninety degrees ± five degrees
• Feedback: Two Auxiliary Switches
• Enclosure Rating: IP67 Waterproof
• Ambient Temperature: -30 °C to +65 °C
• Manual Override: Non-clutch design
• Worm Gear: Permanently lubricated and self-locking
• Space Heater: Fifteen watts 220V Anti-condensation
• External Coating: Dry powder coating
• Stall Protection: Built-in thermal protection, cut off at one hundred twenty-five degrees ± five degrees.
