Homac® SASL-4/0-48 Compression Cable Lug 4/0 AWG to 250 KCMIL

Product Description

The Homac® SASL-4/0-48 is a compression cable lug designed for use with conductors ranging from four/0 AWG to two hundred fifty kcmil, including ACSR, copper, and compact stranded types. This lug features a two-hole stacking design for enhanced connectivity and ease of installation.

• Compatible with dual-rated aluminum and copper conductors.
• All lugs are marked for quick identification of conductor sizes and die references.
• Reduces die inventory as the entire conductor range can be installed by just four dies.

Product Highlights

This compression connector is essential for general electrical applications and is ideal for installation on Homac 125 series insulated buses.

Product Information

Standard Information

• Brand: Homac®
• Manufacturer: ABB

Technical Specifications

• Material: Aluminum
• Approval: UL, CSA
• Overall Length: 3-1/2 inches
• Barrel Type: Straight
• Conductor Size: 4/0 AWG to 250 kcmil, 250 to 300 kcmil
• Mounting Hole Size: 17/32 inches Diameter
• Tongue Size: 1-3/16 inches L x 1-15/64 inches W x 19/64 inches THK
• Die Code: TX, 76, 249, 840, CSA24
• Number Of Pad Holes: 1
