Product Description
The Holdrite V-2 is a copper-bonded steel bracket designed to support horizontal water headers. It holds a load rating of two hundred fifty pounds and accommodates pipe sizes ranging from one-half inch to three inches. This bracket is ideal for pre-fabrication at the shop or on the job site.
- Supports pipe sizes from one-half inch to three inches.
- Overall dimensions are four and one-half inches length and four and one-half inches width.
- Features self-locking stainless steel band and isolating felt pad.
Product Highlights
This bracket mounts to waste or vent pipes, offering a reliable solution before studs are erected in plumbing chase walls.
Product Information
Standard Information
-
Category: Hangers & Supports > Braces and Brackets > Brackets
-
Brand: Holdrite
-
UPC: 67111910002
Technical Specifications
-
Material: 16 Gauge Copper Bonded Cold Rolled Steel
-
Pipe Size: 1/2 to 3 Inch CTS
-
Load Rating: 250 Pounds
-
Overall Dimensions: 4-1/2 Inch Length x 4-1/2 Inch Width
-
Applicable Standard: IAPMO, UPC, IPC
-
Inclusions/Features: 5 Inch Self-Locking Stainless Steel Band, Isolating Felt Pad
