HOLDRITE HR100137 316 Stainless Steel Strut Mount Cushion Clamp

Product Description

The HOLDRITE HR100137 is a strut mount cushion clamp made from durable 316 stainless steel. It is designed to prevent metal-to-metal contact between pipes, clamps, and struts. This clamp effectively resists fuels, oils, gases, greases, solvents, and mineral acids. It allows for simple addition or removal of piping without disturbing adjacent lines and accommodates different pipe sizes.

• Eliminates metal-to-metal contact.
• Simple installation with nylon insert locknut.
• Compatible with copper and PEX materials.

Product Highlights

This clamp is ideal for installations in challenging environments, ensuring reliability and functionality.

Product Information

Standard Information

• Brand: HOLDRITE
• MPN: HR100137

Technical Specifications

• Material: 316 Stainless Steel
• Pipe O.D.: 1 3/8 inches
• Design Load 1: 600 lb
• Design Load 2: 75 lb
• Design Load 3: 75 lb
• Operating Temperature [Min]: -65°F
• Operating Temperature [Max]: 275°F
• Box Qty.: 20
