Holdrite 702 Pex Stub-out Clamp 3/4 Inch

Product Description

The HOLDRITE 702 is a 3/4-inch PEX stub-out clamp designed to secure water heater supply line connections at the wall or framing. It eliminates the need for special tools, solder, glue, or additional hardware. The clamp inserts directly into a compatible bracket and tightens by hand, reducing installation time on rough-in plumbing work. Licensed plumbers and pipefitters install this clamp during new construction and remodel projects where PEX supply lines terminate at water heater stub-out locations.

The HOLDRITE 702 is intended for use with 3/4-inch PEX tubing in residential plumbing applications. It is specifically designed to pair with the HOLDRITE 103-18-LW bracket to form a complete stub-out support assembly. This combination is commonly used at water heater connections where a clean, secure, and tool-free termination point is needed at the wall. The clamp holds the PEX line firmly in position to prevent movement at the stub-out.

Key Features

• Fits 3/4-inch PEX tubing for water heater stub-out applications
• Tool-free installation — insert into bracket and hand-tighten
• No soldering, gluing, or additional hardware required
• Designed to pair with HOLDRITE 103-18-LW bracket for a complete support assembly
• Simplifies rough-in plumbing on new construction and remodel jobs

Compatibility

Designed for use with HOLDRITE bracket 103-18-LW as a complete water heater stub-out support solution for 3/4-inch PEX supply lines.

Installation Notes

Installation is performed by a licensed plumber during rough-in or finish plumbing work. Shut off the water supply and depressurize the line before working on any stub-out connection. Insert the 702 clamp into the 103-18-LW bracket and hand-tighten — no tools are required. Follow all applicable local plumbing codes and IPC guidelines for PEX support and stub-out spacing.

Technical Specifications

• Tubing Size: 3/4 inches
• Tubing Type: PEX
• Application: Water heater stub-out support
• UPC: 67111985

Standard Information

• Brand: HOLDRITE
• Manufacturer Part Number: 702
