Hoffman CCA1286 Compact Series Enclosure 125x80x57mm

Product Description

The HOFFMAN CCA1286 compact series enclosure is designed for indoor or outdoor applications, protecting components in corrosive environments. Constructed from cast aluminum with a gray powder coat finish, it features stainless steel captivated cover screws and grounding screws on the back wall. This enclosure meets NEMA 4/4X/12/13 and IP66 standards.

• Constructed from cast aluminum material
• Features stainless steel captivated cover screws placed outside sealed area
• Designed with tongue-and-groove sealing construction

Product Highlights

Compact aluminum enclosure with robust sealing and corrosion protection for diverse environments.

Product Information

Standard Information

• Brand: HOFFMAN
• Manufacturer Part Number: CCA1286

Technical Specifications

• Article Number: 66610
• Height: 4.92in
• Width: 3.15in
• Depth: 2.24in
• Material: Aluminum
• Finish: Powder Coated
• Color: RAL 7042 Gray
• Color Code: RAL 7042
• Thickness: 0.16in
• Mounting: Wall
• Weight: 0.9lb
• UPC: 783510666101
• Standard Packaging Quantity: 1
• Packing Quantity: 1
• Commodity Level Descrip: NEMA Types 4 & 4X Metallic Enclosures, Boxes, Cabinets
• Brand Name: COMPACT, Bulletin CA1
• Manufacturer: Hoffman
• UNSPSC: 39121324
• Commodity Code: 36150
• Type: One Door
• Service Type: Indoor/Outdoor
• Approval: UL 508A, CSA
• Back Panel: CCAP128
• Enclosure: NEMA 4/4X/12/13, IP66
• Cover Type: O-Ring Gasketed, Screw-On
• Additional Info: Applicable Standard IEC 60529; ROHS Compliant
• IP/NEMA Rating: IP66, NEMA 4X, NEMA 4
• Knockouts: No
