Hoffman ASE30X30X6NK Screw-Cover Enclosure Type 1 no Knockouts, 30x30x6

Product Description

The HOFFMAN ASE30X30X6NK screw-cover enclosure, Type 1, is designed for commercial and general industrial applications needing a junction or pull box. It is available in painted or galvanized finishes, with or without knockouts, and in a wide range of sizes. Accessories are available for flush installations and wiring space extensions.

• Unique keyhole screw slots in the cover
• Available with or without knockouts
• Various sizes of easy-to-remove concentric knockouts on all four sides of standard boxes with knockouts

Product Highlights

This steel enclosure features flat, removable covers fastened with plated steel screws and includes provisions for grounding and mounting holes on the back.

Product Information

Standard Information

• Brand: HOFFMAN
• Manufacturer Part Number: ASE30X30X6NK

Technical Specifications

• Article Number: 49519
• Height (H): 30in
• Width (W): 30in
• Depth (D): 6in
• Material: Mild Steel
• Finish: Painted
• Color: Gray
• Color Code: ANSI 61
• Body Thickness: 2.66 mm
• Door Thickness: 12ga
• Knockouts Included: No
• Cover Screw Quantity: 8
• UPC: 783510495190
• Number of Screws: 8
• Standard: CUL Listed Per CSA C22.2 No 40; Type 1; File No. E27525,IEC 60529, IP30,NEMA/EEMAC Type 1,UL 50, 50E Listed; Type 1; File No. E27525
• Style: Painted
• Type: Pull and Junction Boxes
• Brand: nVent Hoffman
• Sub Brand: Hoffman
• 12-Digit UPC: 783510495190
• Product UPC: 78351049519
• Depth: 6 Inch
• Height: 30 Inch
• Width: 30 in
