Hoffman APWK2315NFSS Window Kit 25.50x17.50x.31

Product Description

The HOFFMAN APWK2315NFSS window kit creates a viewing window on enclosure doors. This kit is easy to install and requires a simple rectangular enclosure cut-out. It measures 25.50x17.50x.31 inches and is made of Stainless Steel 304 with a brushed finish. Ideal for indoor and outdoor Type 3R, 4 and 12 applications.

• Window kits of the same size use the same interchangeable cut-out
• The gasket material on all windows is resistant to oils, cutting fluids and many other liquids
• All required hardware is furnished, along with assembly and cut- out instructions

Product Highlights

The window kit is designed for use on Type 4 and 12 enclosures and is suitable for indoor or outdoor applications where corrosion is a problem.

Product Information

Standard Information

• Brand: HOFFMAN
• Manufacturer Part Number: APWK2315NFSS
• Country of Origin: US

Technical Specifications

• IGCC: 4459
• Size: 25.50x17.50x.31 in
• Type: Industrial Door Mounting and Locks
• Color: Unpainted
• Finish: Brushed NO.3
• Material: Stainless Steel 304
• IP Rating: IP66
• Application: Power Distribution; Corrosive Environments; Controls and Drives
• Type Number: Type 4X
• Family group: WIREWAY/ENCLOSURES
• Manufacturer: HOFFMAN
• Accessory Type: Window Kits
• Thickness (Metric): 1.98 mm
• Cutout Size (Metric): 627 x 424 mm
• Thickness (Imperial): 14 ga
• Window Size (Metric): 584 x 381 mm
• Cutout Size (Imperial): 24.69 x 16.69 in
• Window Size (Imperial): 23.00 x 15.00 in
• Article Number: 22070
• UPC: 783510220709
• EAN: 8713574242289
• Standard Packaging Quantity: 1
• Packing Quantity: 1
• Bulletin Number: A80SW
• Enclosure Rating NEMA: 4, 4X, 12, 13
• Frame Dimensions: 25.50" x 17.50"
• Window Dimensions: 23.00" x 15.00"
• Required Cutout Dimensions: 24.69" x 16.69"
• ECCN: EAR99
• Height: 17.5 in.
• Depth: 0.31 in.
• Width: 25.5 in.
• Category: Boxes, Enclosures, Racks
• Box Components: Box Components
• Packaging: Bulk
• Manufacturer Part Number: APWK2315NFSS
• Numeric ID: 2510415
• UPC Code: 78351022070
• Brand: nVent HOFFMAN
• Dimensions: 2.50 in H X 28.50 in W X 20.80 in L
