Hoffman APWK175NF Window Kit Type 4 and 12, 19.50x8.00x.31

Product Description

The HOFFMAN APWK175NF window kit is designed for creating a viewing window on enclosure doors. Measuring 19.50x8.00x.31 inches, it is constructed from mild steel with a gray finish. This kit is suitable for indoor and outdoor Type 3R, 4 and 12 applications and requires a simple rectangular enclosure cut-out.

• Window kits of the same size use the same interchangeable cut-out
• The gasket material on all windows is resistant to oils, cutting fluids and many other liquids
• All required hardware is furnished, along with assembly and cut- out instructions

Product Highlights

Create a viewing window on enclosure doors with this NEMA 4/3R/12 rated window kit.

Product Information

Standard Information

• Brand: HOFFMAN
• Manufacturer Part Number: APWK175NF
• Country of Origin: US - United States

Technical Specifications

• Article Number: 21890
• Material: Mild Steel
• Finish: Powder Coated
• Color: Gray
• Color Code: ANSI 61
• Thickness: 14ga
• Window Size: 17.00 x 5.50in
• Cutout Size: 18.69 x 7.19in
• UPC: 783510218904
• Standard Packaging Quantity: 1
• Packing Quantity: 1
• Bulletin Number: A80W
• Type: Window Kit
• NEMA Rating: 3R, 4, 12
• Use With: Enclosures
• Color Family: Gray
• ECCN: EAR99
• UNSPSC: 39121321
