Hoffman APWK138NF Window Kit Type 4 and 12 15.50x10.50x.31

Product Description

The HOFFMAN APWK138NF window kit is easy to install and requires a simple rectangular enclosure cut-out. It is ideal for indoor and outdoor Type 3R, 4 and 12 applications. Constructed from mild steel with a gray ANSI 61 powder-coated finish, the window kit features a clear window made of .25-in. (6mm) impact-resistant polycarbonate material.

• Window kits of the same size use the same interchangeable cut-out
• The gasket material on all windows is resistant to oils, cutting fluids and many other liquids
• All required hardware is furnished, along with assembly and cut- out instructions

Product Highlights

This window kit is suitable for controls and drives, and power distribution applications. It meets IP66, NEMA 12, 13, and 4X enclosure type standards.

Product Information

Standard Information

• Brand: HOFFMAN
• Manufacturer Part Number: APWK138NF
• Country of Origin: United States

Technical Specifications

• Article Number: 23950
• Material: Mild Steel
• Finish: Powder Coated
• Color: Gray
• Color Code: ANSI 61
• Thickness: 14ga
• Window Size: 13.00 x 8.00in
• UPC: 783510239503
• EAN: 8713574253810
• Standard Packaging Quantity: 1
• Packing Quantity: 1
• Bulletin Number: A80W
• Applications: For Controls and Drives, Power Distribution
• Enclosure Type: IP66, NEMA 12, 13, 4X
• Standard: 12,13,4X (stainless Steel Version Only),CSA Type 4,File No. 42186,File No. E61997,IEC 60529,IP66,NEMA/EEMAC 4,Type 4,UL 508A Component Recognized
• Type: Window Kits
• Brand: nVent Hoffman
• Sub Brand: Hoffman
