NVENT Hoffman A604CHNF NEMA 4 Piano Hng Jic Bx (6x4x3 in)
NVENT Hoffman A604CHNF NEMA 4 Piano Hng Jic Bx (6x4x3 in)

Hoffman A604CHNF NEMA 4 Piano Hng Jic Bx (6x4x3 in)

Brand: NVENT
SKU: A604CHNF
Availability: Out Of Stock
$158.05
$158.05
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The HOFFMAN A604CHNF is a continuous hinge enclosure with clamps, NEMA Type 4, measuring 6x4x3 inches, constructed from mild steel and finished with a gray powder coating. Designed for both indoor and outdoor use, it provides environmental protection and security. Ideal for controls and drives applications.

  • Seams continuously welded and ground smooth
  • Stainless steel screw-down clamps on three sides of door
  • External wall-mounting brackets for easy installation

Product Highlights

Provides environmental protection and security with a continuous hinge and stainless steel clamps.

Product Information

Standard Information

  • Brand: HOFFMAN
  • Manufacturer Part Number: A604CHNF
  • Country of Origin: Mexico
Technical Specifications
IGCC
4417
Size
6.00x4.00x3.00 in
Type
Mild Steel Industrial Terminal and Junction Boxes
Color
Gray
Depth
3 in
Panel
A6P4
Width
4 in
Finish
Polyester Powder
Material
Mild Steel
IP Rating
IP66
Color Code
ANSI 61
Application
Controls and Drives
NEMA Rating
NEMA 4, 12, 13
Type Number
Type 4
Family group
WIREWAY/ENCLOSURES
Manufacturer
HOFFMAN
Height (Metric)
152 mm
Conductive Panel
A6P4G
Height (Imperial)
6 in
Mounting (Metric)
171 x 51 mm
Protection Rating
NEMA Type 12
Thickness (Metric)
1.52 mm
Mounting (Imperial)
6.75 x 2.00 in
Panel Size (Metric)
124 x 73 mm
Thickness (Imperial)
16 ga
Modification Services
Yes
Panel Size (Imperial)
4.88 x 2.88 in
Overall Dimensions (Metric)
191 x 125 mm
Overall Dimensions (Imperial)
7.50 x 4.94 in
Article Number
55700
UPC
783510557003
EAN
8713574282599
Standard Packaging Quantity
1
Packing Quantity
1
Bulletin Number
A51NF
Applications
For Indoor or Outdoor use
Cover Type
Continuous Hinged with Clamp
Gauge
14 and 16
Standard
12,13,50E Listed,CUL Listed Per CSA C22.2 No. 94,File No. E27567,File No. E61997,NEMA/EEMAC Type 4,Type 4,UL 50,UL 508A Listed
Brand
nVent Hoffman
Sub Brand
Hoffman
12-Digit UPC
783510557003
Product UPC
78351055700
IP/NEMA Rating
IP66, NEMA 4
Mounting
Wall
Special Program
Hoffman On Demand
Enclosure Type
Electrical / Industrial
Enclosure Material
Steel
External Height - Metric
152.4mm
External Width - Metric
102mm
External Depth - Metric
76mm
Body Color
Gray
External Height - Imperial
6"
External Width - Imperial
4"
External Depth - Imperial
3"
MFR #
A604CHNF
Zoro #
G7556701
UPC #
783510282936
Item
Electrical Enclosures
NEMA Enclosure Rating
12, 13, 4
Closure Method
Screw Down Clamps
Cover Closure Type
Hinged
Knockouts
No
Metallic / Non-Metallic
Metallic
Cover Style
Solid
Enclosure Cover Features
Quick Release Latch
Metal Gauge
14/16 ga
Interior Panel
32FR89
Standards
CSA, File No 42184: Type 4 and 12, cUL Listed Per CSA C22.2 No 94, File No E27567, File No E61997, IEC 60529, NEMA/EEMAC Type 4, 12, 13, Type 4, 12, 13, UL 50, 50E Listed, UL 508A Listed
Gasket
Neoprene
Series
A51NF
Features
External-Wall Mounting Bracket
Includes
Screws
Includes Knockouts
Knockouts Not Included
Compatible Panel Model Number
A6P4, A6P4G
Environment - MERCH
Washdown
Gasket Material
Neoprene
Nominal Width
4 in
Nominal Height
6 in
Nominal Depth
3 in
Body Material Thickness
16 ga
