Hoffman A423012LP Continuous Hinge Enclosure with Clamps LP Type 4, 42x30x12

Product Description

The HOFFMAN A423012LP is a single-door enclosure suitable for indoor and outdoor applications. It features stainless steel hardware, including screw-down door clamps and a heavy-gauge hinge. The enclosure is finished inside and out with a polyester powder paint for enhanced corrosion protection. Measures 42x30x12 inches with a material of Steel colored Gray.

• Seams continuously welded and ground smooth
• External, welded-on mounting brackets for wall-mounting
• Formed external return flanges around all sides of enclosure opening

Product Highlights

This enclosure provides access and security with screw-down clamps and a padlocking hasp. Ideal for controls, drives, and other applications requiring environmental protection.

Product Information

Standard Information

• Brand: HOFFMAN
• Manufacturer Part Number: A423012LP
• Country of Origin: United States

Technical Specifications

• Article Number: 27960
• Height: 42 in
• Width: 30 in
• Depth: 12 in
• Color: Gray
• Color Code: ANSI 61
• Material: Mild Steel
• Finish: Powder Coated
• Thickness: 14ga
• Clamp Quantity: 6
• Data Pocket: Small
• UPC: 783510279608
• Bulletin Number: A12
• Applications: Controls and Drives, Indoor
• Body Gauge: 14
• Cover Type: Continuous Hinge with Clamps
• Gauge: 14 ga Body
• Mounting Type: Wall
• Size: 42.00x30.00x12.00 in
• Standard: 13,CSA,CUL Listed Per CSA C22.2 No. 94,File No. 42186: Type 12,File No. E61997,IEC 60529,IP65,NEMA/EEMAC Type 12 And 13,Type 12,UL 508A Listed
• Type: Single Door, Double Lock, Dust-Resistant, Gangable
• Brand: nVent Hoffman
• Sub Brand: Hoffman
• 12-Digit UPC: 783510279608
• Product UPC: 78351027960
• Length: 46-3/4 Inch
• ECCN: EAR99
• NEMA Rating: 12, 13
• Hinge Type: Continuous
• Latch: Screw-Down Clamps
• NEMA Enclosure Rating: 12, 13
• Enclosure Material: Steel
• Closure Method: Screw Down Clamps with Padlocking Hasp
• Cover Closure Type: Hinged
• Knockouts: No
• Metallic / Non-Metallic: Metallic
• Mounting: Wall
• Cover Style: Solid
• IP Rating: IP65
• Features: Mounting Holes
• Interior Panel: 32FT64
• Metal Gauge: 14/16 ga
• Standards: CSA, File No 42186: Type 12, cUL Listed Per CSA C22.2 No 94, File No E61997, IEC 60529, NEMA/EEMAC Type 12 and 13, UL 508A Listed
• Gasket: Neoprene
• Series: A12
• Enclosure Cover Features: Clamps
• Gasket Material: Seamless Foam-In-Place
• Includes Knockouts: Knockouts Not Included
• Compatible Panel Model Number: A42P30, A42P30G
• Environment - MERCH: Dust Tight
• Nominal Width: 30 in
• Nominal Height: 42 in
• Nominal Depth: 12 in
• Body Material Thickness: 14 ga
