Hoffman A1412SC Screw Cover Enclosure 14.00x12.00x6.00

Product Description

The HOFFMAN A1412SC screw cover enclosure is ideal for a broad range of applications. The screw cover is secured in each corner for a positive seal but is easily removed for modifications. It features continuously welded and ground smooth seams, a bonding provision on the cover, and an oil-resistant gasket.

• Seams continuously welded and ground smooth
• Bonding provision on cover
• Oil-resistant gasket

Product Highlights

The HOFFMAN A1412SC enclosure provides secure protection for sensitive components in various industrial environments.

Product Information

Standard Information

• Brand: HOFFMAN
• Manufacturer Part Number: A1412SC

Technical Specifications

• Article Number: 54380
• Height: 14in
• Width: 12in
• Depth: 6in
• Material: Mild Steel
• Finish: Powder Coated
• Color: Gray
• Color Code: ANSI 61
• Thickness: 14ga
• Mounting: 14.75 x 10.00in
• Overall Dimensions: 15.50 x 12.28in
• UPC: 783510543808
• Standard Packaging Quantity: 1
• Packing Quantity: 1
• Bulletin Number: A51SC
• UNSPSC: 39121303
• Application: For broad range of applications, this enclosure's screw cover is secured in each corner for a positive seal but easily removed for modifications
• Mounting Type: Wall
• Series: A51SC
• Cover Type: Screw/Solid
• Panel Size: 12.75 x 10.88
• Dimension F: 5.53 in
• Dimension T: 11 in
• Dimension K: 0.67 in
• Dimension Y: 0.62 in
• A x B x C: 14 x 12 x 6 in
• J Dimension: 5.51 in
• Dimension V: 0.25 in
• Mounting G x H: 14.75 x 10.00 in
• Gauge: 14 ga
• Type: 12
• Conductive Panel: A14P12G
• Description: Type 12 Screw Cover
• Manufacturers Part Number: A1412SC
• Panel: A14P12
• Brand: Hoffman
• Compliance & Certifications: UL Listed 50, 50E
