Hoffman A12R84 Screw-Cover Drip-Shield Type 3R With Knockouts 12x8x4

Product Description

The HOFFMAN A12R84 is a Drip-Shield Screw-Cover, Type 3R enclosure used as a wiring or junction box to protect controls in outdoor applications requiring protection from rain, sleet, snow, or dripping water. It features a slip-on removable cover fastened with plated steel screws. The enclosure is finished with paint over plated surfaces.

• Drip shield top and seam-free sides, front, and back protect from rain, snow, or sleet
• Slip-on removable cover fastened with plated steel screws along bottom edge
• Embossed mounting holes on back of enclosure

Product Highlights

The HOFFMAN A12R84 enclosure provides reliable protection for controls in outdoor environments, featuring a drip shield design and a secure screw cover.

Product Information

Standard Information

• Brand: HOFFMAN
• Manufacturer Part Number: A12R84
• Country of Origin: MX - Mexico

Technical Specifications

• Article Number: 38070
• Height: 12 in
• Width: 8 in
• Depth: 4 in
• Material: Mild Steel
• Finish: Galvanized; Powder Coated
• Color Code: ANSI 61
• Body Thickness: 16ga
• Door Thickness: 16ga
• Knockouts Included: Yes
• Knockout Pattern: F-G-H-I
• Mounting: 1.06in
• Body Style: A
• UPC: 783510380700
• Standard Packaging Quantity: 1
• Packing Quantity: 1
• Bulletin Number: A90S3
• Mounting Type: Wall
• Series: A90S3
• Cover Type: Screw
• Approximate Depth: 4 in
• Approximate Height: 12 in
• Approximate Width: 8 in
• Brand: nVent HOFFMAN
• Manufacturer Part Number: A12R84
• Type: Junction Box
• UPC Code: 78351038070
• IP/NEMA Rating: NEMA 3R, NEMA 3
• Number of Knockouts: 4
• Knockouts: Yes
• Application: For outdoor application as a wiring or junction box
