Hoffman 404424 B3015A 1 Inch Inverted Bucket Steam Trap 15 LB Threaded Connection

Product Description

The Hoffman model 404424 is a robust 1 inch inverted bucket steam trap designed for efficient condensate removal in a variety of applications. Built by a leading brand in steam management systems, this cast iron steam trap is widely recognized for its reliability and performance.

• Highly durable with a maximum temperature tolerance of 450 degrees Fahrenheit.
• Threaded connections simplify installation and maintenance.
• Designed to handle up to 250 PSI of minimum pressure.

Product Highlights

This streamlined steam trap offers precise performance with a body constructed from cast iron, ensuring extended usability and resistance to high temperatures and pressures. Its inverted bucket mechanism provides a reliable, mechanical means of discharging air and condensate without allowing the escape of steam.

Product Information

Standard Information

• Brand: Hoffman
• MPN: 404424

Technical Specifications

• Type: Mechanical Components - Inverted Bucket Steam Trap
• Material: Cast Iron
• Connection Type: Threaded
• Max Temperature: 450°F
• Minimum Pressure: 250 PSI
• Dimensional Weight: 35 pounds
• Unit Size: 1 inch
• Product Category: HVAC - Steam Traps
