Hikvision DS-2CD2583G2-IS 2.8mm 8 MP AcuSense Fixed Mini Dome Network Camera REPLACEMENT DS-2CD2563G0-IS 2.8MM

Product Description

The Hikvision DS-2CD2583G2-IS 2.8mm is an 8 MP AcuSense fixed mini dome network camera delivering high-quality imaging. It features 120 dB WDR technology for clear imaging against strong backlight and efficient H.265+ compression technology. The camera focuses on human and vehicle targets classification based on deep learning and is water and dust resistant (IP67) and vandal resistant (IK08).

• High quality imaging with 8 MP resolution
• Clear imaging against strong backlight due to 120 dB WDR technology
• Efficient H.265+ compression technology

Product Highlights

This mini dome network camera is ideal for outdoor surveillance, providing detailed footage and reliable performance in various conditions. It supports audio and alarm interface.

Product Information

Standard Information

• Brand: HIKVISION
• Manufacturer Part Number: DS-2CD2583G2-IS 2.8mm
• Country of Origin: China

Technical Specifications

• Image Sensor: 1/2.8″ Progressive Scan CMOS
• Max. Resolution: 3840 × 2160
• Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
• Shutter Time: 1/3 s to 1/100,000 s
• Day & Night: IR cut filter
• Angle Adjustment: Pan: -30° to 30°, tilt: 0° to 75°, rotate: 0° to 360°
• Lens Type: Fixed Lens
• Focal Length & FOV: 2.8 mm, horizontal FOV 106.4°, vertical FOV 58.4°, diagonal FOV 124.8° 4 mm, horizontal FOV 87.6°, vertical FOV 44.4°, diagonal FOV 104.9°
• Lens Mount: M12
• Iris Type: Fixed
• Aperture: F1.6
• Depth of Field: 2.8 mm: 1.4 m to ∞ 4 mm: 2.1 m to ∞
• DORI 2.8 mm: D: 88 m O: 35 m R: 18 m I: 9 m
• DORI 4 mm: D: 118 m O: 47 m R: 24 m I: 12 m
• Supplement Light Type: IR
• Supplement Light Range: Up to 30 m
• Smart Supplement Light: Yes
• IR Wavelength: 850 nm
• Main Stream: 50 Hz: 20 fps (3840 × 2160) 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 20 fps (3840 × 2160) 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
• Sub-Stream: 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
• Third Stream: 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.
• Video Compression: Main stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
• Video Bit Rate: 32 Kbps to 16 Mbps
• H.264 Type: Baseline Profile/Main Profile/High Profile
• H.265 Type: Main Profile
• Bit Rate Control: CBR/VBR
• Scalable Video Coding (SVC): H.264 and H.265 encoding
• Region of Interest (ROI): 1 fixed region for main stream and sub-stream
• Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
• Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps (MP2L2)/8-320 Kbps (MP3)/16-64 Kbps (AAC-LC)
• Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
• Environment Noise Filtering: Yes
• Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket, WebSockets
• Simultaneous Live View: Up to 6 channels
• API: Open Network Video Interface (Profile S, Profile G), ISAPI, SDK
• User/Host: Up to 32 users. 3 user levels: administrator, operator and user
• Security: Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
• Network Storage: NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
• Client: iVMS-4200, Hik-Connect, Hik-Central
• Web Browser: Plug-in required live view: IE 10, IE 11 Plug-in free live view : Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+
• Image Parameters Switch: Yes
• Image Settings: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
• Day/Night Switch: Day, Night, Auto, Schedule
• Wide Dynamic Range (WDR): True WDR 120dB
• SNR: ≥ 52 dB
• Image Enhancement: BLC, HLC, 3D DNR
• Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
• On-Board Storage: Built-in memory card slot, support microSD card, up to 512 GB
• Built-in Microphone: Yes
• Audio: Yes
• Alarm: -IS: 1 input, 1 output (max. 12 VDC, 20 mA)
• Reset Key: Yes
• Basic Event: Motion detection (human and vehicle targets classfication), video tampering alarm, exception
• Smart Event: Line crossing detection, intrusion detection, face detection
• Linkage: Upload to FTP/memory card/NAS, notify surveillance center, trigger recording, trigger capture, send email
• Power: 12 VDC ± 25%, 0.54 A, max. 6.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection PoE: (802.3af, Class 3, 36 V to 57 V, 0.22 A to 0.14 A, max. 8 W
• Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• General Function: Anti-flicker, heartbeat, password reset via e-mail, pixel counter
• EMC: FCC (47 CFR Part 15, Subpart B) CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014) RCM (AS/NZS CISPR 32: 2015) IC (ICES-003: Issue 7) KC (KN32: 2015, KN35: 2015)
• Safety: UL (UL 62368-1) CB (IEC 62368-1: 2014+A11) CE-LVD (EN 62368-1: 2014/A11: 2017)
• Environment: CE-RoHS (2011/65/EU) WEEE (2012/19/EU) Reach (Regulation (EC) No 1907/2006)
• Protection: IP67: IEC 60529-2013,IK08: IEC 62262:2002
• Features: 3D Digital Noise Reduction, Back Light Compensation (BLC), Built-in Microphone, Day/Night, Gain Control, Highlight Compensation (HLC), Motion Detection, Password Protection, SD Card Local Storage, White Balance
• Manufacturer: Hikvision
• Camera Signal: Network IP
• Connection Type: Wired
• Infrared Distance: 61~100 Feet
• Resolution: 8 Megapixel
• Lens Size: 2.8mm
• Mount Type: Ceiling Mount, Corner Mount, Pole Mount, Wall Mount
• Compression Method: H.264, M-JPEG, H.265, H.264+, H.265+
• Durability: Vandal Resistant, Weather Resistant
• Voltage: 12vDC, PoE
• Automatic Gain Control (AGC): Auto/Manual
• Electronic Shutter: 1/3 s to 1/100,000 s
• Minimum Scene Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
• Operating Humidity: 95% or less (non-condensing)
• Operating Temperature: -30 °C to 60 °C (-22 °F to 140 °F).
• Weatherproof: IP67
• Digital Noise Reduction: Yes
• IR Distance: Up to 30 m
• Auto Gain Control: Yes
• Day/Night: Yes
• Automatic White Balance: Yes
• Back Light Compensation: Yes
• Motion Detection Tracking: Yes
• Privacy Masking: Yes
• Wide Dynamic Range: Yes
• ONVIF: Yes
• Brand: Hikvision
• Part Number: DS-2CD2583G2-IS 2.8MM
• Camera Style: Mini Dome
• Environmental: Outdoor
• Manufacturer Website: https://us.hikvision.com/en
• Product Series: Hikvision Value Series
• Protection Code: IP67
• Special Technologies: Hikvision AcuSense
• Technology: Network (IP)
• Alternative SKUs: DS-2CD2583G2-IS(2.8mm), DS-2CD2583G2-IS-2-8mm
• Power Type: PoE
• Product Type: Network Camera
• Connectivity Technology: Wired
• Effective Camera Resolution: 8MP
• Field of View: Diagonal, Horizontal, Vertical
• Maximum Aperture: f/1.6
• Maximum Frame Rate: 30fps
• Minimum Focal Length: 2.8mm
• Night Vision: Yes
• Night Vision Type: Infrared
• Video Formats: H.264, H.265, MJPEG
• Image Sensor Type: CMOS
• Night Vision Distance: 98.43 ft
• Ingress Protection Rating: IP67
• NDAA Compliant: No
• TAA Compliant: No
• Maximum Video Resolution: 3840 x 2160
• Maximum Operating Temperature: 140°F (60°C)
• Minimum Operating Temperature: -22°F (-30°C)
• Focal Length: 2.8mm
• Lens Included: Yes
• Maximum Focal Length: 2.8mm
• Remote Management: Yes
• ADI Part Number Replaces: HX-CD2563F2
• Model Number Replaces: DS-2CD2563G0-IS 2.8MM
• Form Factor: Mini Dome
• Recording Formats: 4K
• Storage Type: Memory Card
• Maximum Resolution: 8MP
• Impact Protection Rating: IK08, IK10
• Indoor/Outdoor: Outdoor
• Diameter: 4.5"
