Honeywell LSM6D MICRO SWITCH HDLS Series Heavy-Duty Limit Switch, Plug-in, Side Rotary, 2NC 2NO DPDT Center Neutral, 0.5 in - 14NPT conduit

Product Description

The Honeywell LSM6D is a heavy-duty limit switch designed for industrial use. This MICRO SWITCH HDLS series product features a plug-in side rotary actuator with a dual contact configuration of 2NC and 2NO in a DPDT setup. It can handle voltages up to 600 VAC and 250 VDC, making it suitable for various applications in machine tools, material handling, and packaging.

• Contact Configuration: 2NO-2NC/DPDT
• NEMA rated enclosure suitable for outdoor and harsh environments
• Designed for temperatures from -1 to 121 degrees Celsius

Product Highlights

Engineered for reliability, the Honeywell LSM6D ensures secure operation in critical applications. It complies with various standards, enhancing its versatility and safety.

Product Information

Standard Information

• Manufacturer: Honeywell
• Catalog Number: LSM6D

Technical Specifications

• Voltage Rating: 600 VAC/250 VDC
• Amperage Rating: 10 A
• Connection Type: 1/2-14 NPT
• Operating Temperature: -1 to 121 degrees Celsius
• Size: 47.8 mm L x 45.5 mm W x 89.7 mm H
• Enclosure: NEMA 1/3/4/4X/6/6P/12/13
• Material: Die Cast Zinc
• Application: For machine tools, material handling, packaging, presses, and welding
