Heatlink 75112 12 Loop 1-1/4 inches SS Manifold with Flow Meters

Product Description

The HEATLINK 75112 is a 12-loop 1-1/4" stainless steel manifold designed for precise flow control in heating systems. It features a 1-1/4" trunk size and connection, with 12 branches, and includes 1" FNPT isolation valves, thermometers, and hose bib/air vents. A lockable 0-2 US gpm visual flow meter allows for fine-tune balancing of each loop, while the return manifold valves accept optional actuators for automated control.

• 2 US gpm flow meters
• 1" FNPT supply and return isolation valves
• Supply and return hose bibs

Product Highlights

This manifold provides precise flow balancing, individual loop isolation, and readiness for automated control in hydronic systems.

Product Information

Standard Information

• Brand: HEATLINK
• Manufacturer Part Number: 75112
• Country of Origin: ITALY

Technical Specifications

• Type: Manifolds
• Material: Stainless Steel
• Trunk Size: 1-1/4"
• Number of Branches: 12
• Trunk Connection Size: 1-1/4"
• Number of Outlets: 24
• Circuit Spacing: 8.1 in
• Connection Type: FNPT
• Flow Rate: 2 gpm
• Material Standard: ASTM B124 C37700, ASTM/AISI 304 EN10088 1.4306
• Measuring Range: 32 to 175 deg F
• Mounting Type: Bracket
• Outlet Center Distance: 1.97 in
• Pressure Rating: 87 psi
• Temperature Rating: 32 to 160 deg F
